液化石油气瓶直阀6620212
在线订购
产品名称 | 液化石油气瓶直阀 | Product name | LPG Cylinder Straight Valve | |
型号 | 6620212 | Model | 6620212 | |
工作压力 | 250PSI (1.7MPa) | Working pressure | 250PSI (1.7MPa) | |
公称通径 | 6mm | Seal diameter | 6mm | |
进口螺纹 | PZ27.8 (PZ27.8-LH) | Inlet thread | PZ27.8 (PZ27.8-LH) | |
出口外径 | 20mm | Outlet Ext Dia | 20mm | |
安全释放压力 | 2.4-3.5MPa | Safety release pressure | 2.4-3.5MPa | |
主材 | 黄铜HPb 59-1。其它牌号可提供 | Main material | Brass HPb 59-1. Other numbers are available. | |
有其它多个规格,或订做 | There are many other specifications, or customized. |
